Dagger Rotating Nozzle

Dagger Rotating Nozzle

Pipe cleaning 1500 bar (22.000 psi), 150 - 450 mm

The affordable Dagger high pressure rotary nozzle is suitable for descaling, intense cleaning and removal of corrosion, crude oil, coke, polymers, coatings and latex from 150 - 450mm pipes and tubes with high pressure up to 1500 bar (22.000 psi).
The rotation speed of the nozzle can be adjusted by changing the fluid inside the nozzle. With the adjustable centralizers, the Dagger has a wide range of applications for 150 - 450mm pipes.

The Dagger is available in 2 different versions:
Head 1: 2x 45⁰, 2x 90⁰, 2x 135⁰
Head 2: 2x 45⁰, 2x 90⁰, 2x 135⁰, 1x 165⁰

Contact PRO-JETTING now for pricing and more information or to discuss your specific jobs!

Download Brochure

Dagger Rotating Nozzle

Pipe cleaning 1500 bar (22.000 psi), 150 - 450 mm

The affordable Dagger rotating nozzle for descaling, intense cleaning and removal of coatings from 150 - 450mm pipelines and tubes with high pressure up to 1500 bar (22.000 psi).

Specifications

Flow: 56 - 130 LPM (15 - 35 GPM)
Max. Pressure: 1500 bar (22.000 psi)
RPM: 50 - 200 rpm
Connections: F 3/4" NPSM
Weight: 5.4 KG
Dimensions: 270mm x ø76mm
Water Temperature: 70 ⁰C (158 ⁰F)
Scope Of Use: 150 - 450mm (6-18")

Features

  • Descaling and internal cleaning of pipes and tubes
  • Very efficient
  • RPM adjustable by changing the fluid
  • Available in 2 versions

Specifications

Flow: 56 - 130 LPM (15 - 35 GPM)
Max. Pressure: 1500 bar (22.000 psi)
RPM: 50 - 200 rpm
Connections: F 3/4" NPSM
Weight: 5.4 KG
Dimensions: 270mm x ø76mm
Water Temperature: 70 ⁰C (158 ⁰F)
Scope Of Use: 150 - 450mm (6-18")

Features

  • Descaling and internal cleaning of pipes and tubes
  • Very efficient
  • RPM adjustable by changing the fluid
  • Available in 2 versions
