Vortex-SurfaceJet Surface Cleaning Nozzle

Vortex-SurfaceJet Surface Cleaning Nozzle

1000 -1400 bar | 28 - 30 LPM

The Vortex-SurfaceJet High-pressure cleaning nozzles are designed for cleaning curved, flat and irregular surfaces.

The swirl of liquid from the jet creates a shear action to remove coatings and other materials.

The concentrated jet pattern gives a larger pattern than a fan Nozzle while still providing a very high impact at the same time. The protective sleeve reduces the kickback during cleaning.



Download the brochure for more information and technical specifications for the different models.

Download Brochure

Vortex-SurfaceJet Surface Cleaning Nozzle

1000 -1400 bar | 28 - 30 LPM

The Vortex-SurfaceJet cleaning nozzles are designed for cleaning curved, flat and irregular surfaces. The swirl of liquid from the jet creates a shear action to remove coatings and other materials.

Specifications

Pressure: 1000 -1400 bar (15,000 - 20,000 psi)
Flow: 28 - 30 LPM (7,5 - 8 gpm)
Applications: Pipe cleaning, corrosion removal, dirt removal, unblocking, excavation etc.

Features

  • Strip-free cleaning (leaves no marks due to uniform spray pattern)
  • High reliability (no moving parts)
  • Optimal productivity (even spray coverage, little loss of fluid)
  • Robustly designed (minimal wear, no jamming and sensitive nozzle)
  • Ensures a safer workplace (quiet operation)
  • Financially advantageous (less costs in advance, little to no maintenance required)
  • Compact and light
  • Not water retaining

Specifications

Pressure: 1000 -1400 bar (15,000 - 20,000 psi)
Flow: 28 - 30 LPM (7,5 - 8 gpm)
Applications: Pipe cleaning, corrosion removal, dirt removal, unblocking, excavation etc.

Features

  • Strip-free cleaning (leaves no marks due to uniform spray pattern)
  • High reliability (no moving parts)
  • Optimal productivity (even spray coverage, little loss of fluid)
  • Robustly designed (minimal wear, no jamming and sensitive nozzle)
  • Ensures a safer workplace (quiet operation)
  • Financially advantageous (less costs in advance, little to no maintenance required)
  • Compact and light
  • Not water retaining

Overview Available Vortex-SurfaceJet Nozzles

Item Pressure Flow Diameter
VSJ-15K 1000 bar (15,000 psi) 30 LPM (8 gpm) 45 mm (1.79 inch)
VSJ-20K 1400 bar (20,000 psi) 28 LPM (7.5 gpm) 45 mm (1.79 inch)
