Gladius Rotating High Pressure Nozzle

Gladius Rotating High Pressure Nozzle

830 - 1500 bar | 45 - 110 LPM

Gladius is a rotating high-pressure nozzle for water jets, specially designed for manual pipe cleaning. This self-rotating nozzle makes it easy to internally clean pipes with diameters up to 4" (100 mm) without a lead lance. The built-in speed control system allows the operator to adjust the rotation speed (70 or 300 rpm) by choosing between two types of oil. Gladius can be equipped with 5 nozzles and can be used at 110 LPM @ 1500 bar.

Get informed about the available products or download the brochure with more information and technical specifications of different models.

Download Brochure

Gladius Rotating High Pressure Nozzle

830 - 1500 bar | 45 - 110 LPM

Gladius rotary high-pressure nozzle from PRO-JETTING is ideal for cleaning pipes and tubes with diameters up to 4" (100 mm). A rotating nozzle increases the work surface and thus production.

Specifications

Pressure: Max. 1500 bar (22,000 psi)
Flow: 45 - 110 LPM (12 - 29 gpm)
RPM: 70 - 300 RPM
Application: Pipe cleaning
Nozzle type: AP2
Connection: M 3/4" UNF
Weight: 1.9 kg
Dimensions: 108 x ø68 mm
Scope Of Use: 102 - 305 mm (4 - 12")
Water Temperature: 45 ⁰C (140 ⁰F)

Features

  • Very long lifespan
  • Light, durable and reliable
  • Maintenance friendly
  • Very high cleaning power
  • Constant jet flow rate
  • Easy to install and disassemble
  • Good price-performance ratio
  • Available with various threaded connections
  • To be used in combination with a centralizer

Specifications

Pressure: Max. 1500 bar (22,000 psi)
Flow: 45 - 110 LPM (12 - 29 gpm)
RPM: 70 - 300 RPM
Application: Pipe cleaning
Nozzle type: AP2
Connection: M 3/4" UNF
Weight: 1.9 kg
Dimensions: 108 x ø68 mm
Scope Of Use: 102 - 305 mm (4 - 12")
Water Temperature: 45 ⁰C (140 ⁰F)

Features

  • Very long lifespan
  • Light, durable and reliable
  • Maintenance friendly
  • Very high cleaning power
  • Constant jet flow rate
  • Easy to install and disassemble
  • Good price-performance ratio
  • Available with various threaded connections
  • To be used in combination with a centralizer
