Tempest Rotating Nozzle

Tempest Rotating Nozzle

Pipe cleaning 2800 Bar (40.000 psi) , 50 - 150mm

The robust Tempest nozzle is equipped with a rotating nozzle whose speed can be regulated for intensive cleaning of pipes up to 2800 bar (40.000 psi).
The rotating nozzle is suitable for descaling, cleaning and removing corrosion, crude oil, coke, polymers, coatings and latex from pipes and tubes with a diameter of 50 - 150mm managed by the differend centralizers.
Due the internal control system, the nozzle rotation speed can easily controlled from 600 - 1000 rpm.
The Tempest is available as an 'unplugger' with a forward jet or as a 'polisher' without a forward jet:

- Unplugger head: 1x10⁰, 1x 33⁰, 1x40⁰, 2x135⁰
- Polisher head: 3x80⁰, 3x100⁰

Get informed about the available products or download the brochure with more information and technical specifications.

Download Brochure

Tempest Rotating Nozzle

Pipe cleaning 2800 Bar (40.000 psi) , 50 - 150mm

De Tempest 2800 bar (40.000 psi) is a simple and affordable way to remove corrosion, crude oil, polymers, coatings and latex from different sized pipes.

Specifications

Flow: 15 - 30 LPM (4 - 8 GPM)
Max. Pressure: 2.800 bar (40.000 psi)
RPM: 600 - 1000 rpm
Connections: F1.1/8"UNF (9/16"HP)
Weight: 1.2 KG
Dimensions: 200mm x ø42mm
Scope Of Use: 50 - 150mm
Water Temperature: 70 ⁰C (158 ⁰F)

Features

  • Internal cleaning of pipes and tubes
  • High efficiency
  • Sustainable product
  • Easy and inexpensive to maintain
  • Usable for multiple ranged pipes due different centralizers
  • Available as unplugger or as polisher head
  • Magnetic rotation speed control system

Specifications

Flow: 15 - 30 LPM (4 - 8 GPM)
Max. Pressure: 2.800 bar (40.000 psi)
RPM: 600 - 1000 rpm
Connections: F1.1/8"UNF (9/16"HP)
Weight: 1.2 KG
Dimensions: 200mm x ø42mm
Scope Of Use: 50 - 150mm
Water Temperature: 70 ⁰C (158 ⁰F)

Features

  • Internal cleaning of pipes and tubes
  • High efficiency
  • Sustainable product
  • Easy and inexpensive to maintain
  • Usable for multiple ranged pipes due different centralizers
  • Available as unplugger or as polisher head
  • Magnetic rotation speed control system
