Vortex-Jet Pulse Pipe Cleaning Nozzle

Vortex-Jet Pulse Pipe Cleaning Nozzle

1000 - 1400 bar | 22 - 150 LPM

The patented Vortex-Jet High Pressure Nozzles are specially designed for cleaning up mineral corrosion accumulation or completely sealed pipes.

The swirling action of liquid from the forward-facing jet creates a shear action to effectively clean and remove dirt.

The Vortex-Jet Pulse Nozzle uses a patented jet sharpening technology that ensures acceleration of liquids, ultimately resulting in increased productivity and optimum efficiency.



Download the brochure for more information and technical specifications for the different models.

 Download Brochure

Vortex-Jet Pulse Pipe Cleaning Nozzle

1000 - 1400 bar | 22 - 150 LPM

The patented Vortex-Jet High Pressure Nozzles are specially designed for cleaning up mineral corrosion accumulation or completely sealed pipes. The swirling action of liquid from the forward-facing jet creates a shear action to effectively clean and remove dirt.

Vortex-Jet Pulse Demo

Specifications

Pressure: 1000 - 1400 bar (15,000 - 20,000 psi)
Flow: 22 - 150 LPM (3.4 - 42.1 gpm)
Applications: Pipe cleaning, corrosion removal, dirt removal, unblocking, excavation etc.
Connection 15k: 1/16" NPTF, 1/8" NPTF, 1/4" NPTF, 3/8" NPTF, 1/2" NPTF
Connection 20k: 1/4 & 3/8 -28 Female LH or RH, 9/16-18 Female LH or RH, 9/16 MP
Weight: 0.2 kg
Dimensions: 49 - 105 x ø9.5 - 33 mm
Scope Of Use: 12 - 60 mm ( 0.5 - 2.4")
Water Temperature: 95 ⁰C (200 ⁰F)

Features

  • Strip-free cleaning (leaves no marks due to uniform spray pattern)
  • High reliability (long service life and good quality)
  • Optimal productivity (even spray coverage, little loss of fluid)
  • Robustly designed (minimal wear, no jamming and sensitive nozzle)
  • Ensures a safer workplace (quiet operation)
  • Financially advantageous (less costs in advance, little to no maintenance required)
  • No moving external parts

Specifications

Pressure: 1000 - 1400 bar (15,000 - 20,000 psi)
Flow: 22 - 150 LPM (3.4 - 42.1 gpm)
Applications: Pipe cleaning, corrosion removal, dirt removal, unblocking, excavation etc.
Connection 15k: 1/16" NPTF, 1/8" NPTF, 1/4" NPTF, 3/8" NPTF, 1/2" NPTF
Connection 20k: 1/4 & 3/8 -28 Female LH or RH, 9/16-18 Female LH or RH, 9/16 MP
Weight: 0.2 kg
Dimensions: 49 - 105 x ø9.5 - 33 mm
Scope Of Use: 12 - 60 mm ( 0.5 - 2.4")
Water Temperature: 95 ⁰C (200 ⁰F)

Features

  • Strip-free cleaning (leaves no marks due to uniform spray pattern)
  • High reliability (long service life and good quality)
  • Optimal productivity (even spray coverage, little loss of fluid)
  • Robustly designed (minimal wear, no jamming and sensitive nozzle)
  • Ensures a safer workplace (quiet operation)
  • Financially advantageous (less costs in advance, little to no maintenance required)
  • No moving external parts

Overview Available Vortex-Jet Pulse Nozzles

Item Pressure Flow Diameter
VJP06-38-15K 1000 bar (15,000 psi) 22 LPM (5,8 gpm) 9.5 mm (0.375 inch)
VJP09-50-15K 1000 bar (15,000 psi) 34 LPM (9 gpm) 13 mm (0.5 inch)
VJP14-69-15K 1000 bar (15,000 psi) 51,5 LPM (13,6 gpm) 18 mm (0.69 inch)
VJP25-93-15K 1000 bar (15,000 psi) 95,4 LPM (25,2 gpm) 24 mm (0.93 inch)
VJP42-130-15K 1000 bar (15,000 psi) 159,4 LPM (42,1 gpm) 33 mm (1.3 inch)
VJP06-38-20K 1400 bar (20,000 psi) 22 LPM (5,8 gpm) 9.5 (0.375 inch)
VJP09-50-20K 1400 bar (20,000 psi) 33,3 LPM (8,8 gpm) 13 mm (0.5 inch)
VJP14-69-20K 1400 bar (20,000 psi) 53 LPM (14 gpm) 18 mm (0.69 inch)
VJP21-93-20K 1400 bar (20,000 psi) 80,3 LPM (21,2 gpm) 24 mm (0.93 inch)
VJP26-130-20K 1400 bar (20,000 psi) 98,8 LPM (26,1 gpm) 33 mm (1.3 inch)
