Electric High Pressure Unit
High Pressure Units

Electric High Pressure Unit

33 LPM @ 170 bar

The electric HDE170_33 high pressure unit is an economic and effective unit for cavitation cleaning with retro guns, ROV lances and surface rotors. The HDE170_33 is built as a solid cart, requires a 8,8Kw three-phase power supply and is compatible with CW200, CW300, CW250, CW350, CW202ROV, CW303ROV, SR450 and SR600.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric High Pressure Unit

33 LPM @ 170 bar

The electric HDE170_33 high pressure unit is an economic and effective unit for cavitation cleaning with retro guns, ROV lances and surface rotors. The HDE170_33 is built as a solid cart, requires a 8,8Kw three-phase power supply and is compatible with CW200, CW300 CW250, CW350, CW202ROV, CW303ROV, SR450 and SR600.

Specifications

Compatible with: CW200, CW250, CW300, CW350, CW202ROV, CW303ROV, SR450, SR600
Max. Pressure: 170 bar (2,465 psi)
Max. flow: 33 LPM (8.7 GPM)
Power: 8,8Kw, 400v, 50Hz
Weight: 161kg (355lbs)
Dimensions: 90x75x95cm (35.4x29.5x37.4")

Features

  • Removes medium fouling, debris and corrosion
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection

Specifications

Compatible with: CW200, CW250, CW300, CW350, CW202ROV, CW303ROV, SR450, SR600
Max. Pressure: 170 bar (2,465 psi)
Max. flow: 33 LPM (8.7 GPM)
Power: 8,8Kw, 400v, 50Hz
Weight: 161kg (355lbs)
Dimensions: 90x75x95cm (35.4x29.5x37.4")

Features

  • Removes medium fouling, debris and corrosion
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
