Diesel PRO High Pressure Unit
High Pressure Units

Diesel PRO High Pressure Unit

70 LPM @ 280 bar

The diesel engine driven HDMD280_70 high pressure unit is built on a skid with stainless steel pump head for professional offshore cavitation cleaning operations. The 70 LPM water volume at 280 bar provides a lot of both cleaning speed and cleaning power for fast removal of thick marine growth, corrosion and instable coatings. The HDMD280_70 is compatible with CW350, CW450, all ROV cavitation lances, rotor cleaners and underwater tools.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Diesel PRO High Pressure Unit

70 LPM @ 280 bar

The diesel engine driven HDMD280_70 high pressure unit is built on a skid with stainless steel pump head for professional offshore cavitation cleaning. The 70 LPM water volume at 280 bar provides both cleaning speed and cleaning power for fast removal of thick marine growth, corrosion and instable coatings. The HDMD280_70 is compatible with CW350, CW450, all ROV cavitation lances, rotor cleaners and underwater tools.

Specifications

Compatible with: CW300, CW350, CW450, CW202ROV, CW303ROV, Rotor Cleaners, Underwater Tools
Max. Pressure: 280 bar (4,061 psi)
Max. flow: 70 LPM (18.5 GPM)
Power: 51HP Hatz diesel engine
Weight: 850kg (1,875 lbs)
Dimensions: 195x125x150cm (76.8x49.2x59")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives multiple underwater tools
  • Electric start
  • Stainless steel pump head
  • Heavy duty skid
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Big cartridge filter at pump inlet

Specifications

Compatible with: CW300, CW350, CW450, CW202ROV, CW303ROV, Rotor Cleaners, Underwater Tools
Max. Pressure: 280 bar (4,061 psi)
Max. flow: 70 LPM (18.5 GPM)
Power: 51HP Hatz diesel engine
Weight: 850kg (1,875 lbs)
Dimensions: 195x125x150cm (76.8x49.2x59")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives multiple underwater tools
  • Electric start
  • Stainless steel pump head
  • Heavy duty skid
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Big cartridge filter at pump inlet
