Electric PRO High Pressure Unit
High Pressure Units

Electric PRO High Pressure Unit

60 LPM @ 200 bar

The electric HDE200_60PRO high pressure unit is built on a compact, 4 wheeled cart with stainless steel pump head and frequency controller for continuous adjustment of pressure and flow. The high water volume of 60 LPM results in fast cavitation cleaning of hulls and underwater surfaces with CW350, CW450, Rotor Cleaners, all ROV lances and drives all underwater tools.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric PRO High Pressure Unit

60 LPM @ 200 bar

The electric HDE200_60PRO high pressure unit is built on a compact, 4 wheeled cart with stainless steel pump head and frequency controller for continuous adjustment of pressure and flow. The high water volume of 60 LPM results in fast cavitation cleaning of hulls and underwater surfaces with CW350, CW450, Rotor Cleaners, all ROV lances and drives all underwater tools.

Specifications

Compatible with: CW300, CW350, CW450, CW202ROV, CW303ROV, All Rotor Cleaners, All Underwater Tools
Max. Pressure: 200 bar (2,900 psi)
Max. flow: 60 LPM (15.9 GPM)
Power: 26,2Kw, 400v, 50Hz
Weight: 250kg (551lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives all underwater tools
  • Stainless steel pump head
  • Frequency controller for continuous adjustment of pressure and flow.
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop

Specifications

Compatible with: CW300, CW350, CW450, CW202ROV, CW303ROV, All Rotor Cleaners, All Underwater Tools
Max. Pressure: 200 bar (2,900 psi)
Max. flow: 60 LPM (15.9 GPM)
Power: 26,2Kw, 400v, 50Hz
Weight: 250kg (551lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives all underwater tools
  • Stainless steel pump head
  • Frequency controller for continuous adjustment of pressure and flow.
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
