Electric PRO High Pressure Unit
High Pressure Units

Electric PRO High Pressure Unit

85 LPM @ 220 bar

The electric HDE220_85 high pressure unit is built on a skid with stainless steel pump head for offshore cavitation cleaning operations. The high water volume of 85 LPM at 220 bar provides a lot of power for cavitation cleaning with CW350, CW450, ROV lances, rotor cleaners and underwater tools.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric PRO High Pressure Unit

85 LPM @ 220 bar

The electric HDE220_85 high pressure unit is built on a skid with stainless steel pump head for offshore cavitation cleaning operations. The high water volume of 85 LPM at 220 bar provides a lot of power for cavitation cleaning with CW350, CW450, ROV lances, rotor cleaners and underwater tools.

Specifications

Compatible with: CW300, CW350, CW450, CW550, CW202ROV, CW303ROV, Rotor Cleaners, Underwater Tools
Max. Pressure: 220 bar (3,190 psi)
Max. flow: 85 LPM (22.5 GPM)
Power: 37Kw, 400v, 50Hz
Weight: 850kg (1875lbs)
Dimensions: 220x120x120cm (86.6x47.2x47.2")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives multiple underwater tools
  • Stainless steel pump head
  • Heavy duty skid
  • Big cartridge filter at pump inlet
  • Pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Optional Atex certified
  • Available in 60 Hz versions
