Electric PRO High Pressure Unit
High Pressure Units

Electric PRO High Pressure Unit

99 LPM @ 235 bar

The electric HDE235_99 high pressure unit is built on a skid with stainless steel pump head for large offshore cavitation cleaning operations. The high water volume of 99 LPM at 235 bar provides sufficient cleaning power for fast removal of thick marine growth with CW450, CW550 Pro retro gun, SR600 and underwater tools.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric PRO High Pressure Unit

99 LPM @ 235 bar

The electric HDE235_99 high pressure unit is built on a skid with stainless steel pump head for large offshore cavitation cleaning operations. The high water volume of 99 LPM at 235 bar provides sufficient cleaning power for fast removal of thick marine growth with CW450, CW550 Pro retro gun, SR600 and underwater tools.

Specifications

Compatible with: CW300, CW350, CW450, CW550, SR600, Underwater Tools
Max. Pressure: 235 bar (3,410 psi)
Max. flow: 99 LPM (26.2 GPM)
Power: 45Kw, 400v, 50Hz
Weight: 850kg (1875lbs)
Dimensions: 220x120x120cm (86.6x47.2x47.2")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Stainless steel pump head
  • Heavy duty skid
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Optional Atex certified
  • Available in 60 Hz versions

Specifications

Compatible with: CW300, CW350, CW450, CW550, SR600, Underwater Tools
Max. Pressure: 235 bar (3,410 psi)
Max. flow: 99 LPM (26.2 GPM)
Power: 45Kw, 400v, 50Hz
Weight: 850kg (1875lbs)
Dimensions: 220x120x120cm (86.6x47.2x47.2")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Stainless steel pump head
  • Heavy duty skid
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Optional Atex certified
  • Available in 60 Hz versions
