Electric PRO High Pressure Unit
High Pressure Units

Electric PRO High Pressure Unit

31 LPM @ 300 bar

The electric HDE300_31PRO high pressure is built on a compact, 4 wheeled cart and has a stainless steel pump head and a frequency controller for continuous adjustment of pressure and flow. The HDE300_31PRO requires 18,5Kw three-phase power supply to deliver a maximum 300 bar for the compatible CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric PRO High Pressure Unit

31 LPM @ 300 bar

The electric HDE300_31PRO high pressure is built on a compact, 4 wheeled cart and has a stainless steel pump head and a frequency controller for continuous adjustment of pressure and flow. The HDE300_31PRO requires 18,5Kw three-phase power supply to deliver a maximum 300 bar for the compatible CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 300 bar (4,350 psi)
Max. flow: 31 LPM (8.2 GPM)
Power: 18,2Kw, 400v, 50Hz
Weight: 205kg (452lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives all underwater tools
  • Stainless steel pump head
  • Frequency controller for continuous adjustment of pressure and flow.
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 300 bar (4,350 psi)
Max. flow: 31 LPM (8.2 GPM)
Power: 18,2Kw, 400v, 50Hz
Weight: 205kg (452lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes hard fouling, debris, corrosion and coatings
  • Drives all underwater tools
  • Stainless steel pump head
  • Frequency controller for continuous adjustment of pressure and flow.
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
