Diesel High Pressure Unit
High Pressure Units

Diesel High Pressure Unit

42 LPM @ 190 bar

The diesel engine driven HDMD190_42 high pressure unit provides cleaning speed with its 42 LPM flow for cavitation cleaning with the CW350 and ROV lances to remove fouling, oysters, barnacles and other marine life fast. The solid, stand-alone, 4 wheeled cart has a diesel engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Diesel High Pressure Unit

42 LPM @ 190 bar

The diesel engine driven HDMD190_42 high pressure unit provides cleaning speed with its 42 LPM flow for cavitation cleaning with the CW350 and ROV lances to remove fouling, oysters, barnacles and other marine life fast. The solid, stand-alone, 4 wheeled cart has a diesel engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 190 bar (2,755 psi)
Max. flow: 42 LPM (11 GPM)
Power: 23HP Kohler diesel engine
Weight: 190kg (419 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 190 bar (2,755 psi)
Max. flow: 42 LPM (11 GPM)
Power: 23HP Kohler diesel engine
Weight: 190kg (419 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter
