Diesel High Pressure Unit

36 LPM @ 240 bar

The diesel engine driven HDMD240_36 high pressure unit is designed to provide cleaning speed at 240 bar cavitation cleaning with the CW350 and ROV lances to remove marine life and instable coatings. The solid, stand-alone, 4 wheeled cart has a diesel engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Diesel High Pressure Unit

36 LPM @ 240 bar

The diesel engine driven HDMD240_36 high pressure unit is designed to provide cleaning speed at 240 bar cavitation cleaning with the CW350 and ROV lances to remove marine life and instable coatings. The solid, stand-alone, 4 wheeled cart has a diesel engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 240 bar (3,480 psi)
Max. flow: 36 LPM (9.5 GPM)
Power: 23HP Kohler diesel engine
Weight: 190kg (419 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 240 bar (3,480 psi)
Max. flow: 36 LPM (9.5 GPM)
Power: 23HP Kohler diesel engine
Weight: 190kg (419 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter
