Gasoline High Pressure Unit
High Pressure Units

Gasoline High Pressure Unit

36 LPM @ 240 bar

The gasoline engine driven HDMP240_36 high pressure unit is designed to provide cleaning speed at 240 bar cavitation cleaning with the CW350 and ROV lances to remove marine life and instable coatings. The solid, stand-alone, 4 wheeled cart has a gasoline engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Gasoline High Pressure Unit

36 LPM @ 240 bar

The gasoline engine driven HDMP240_36 high pressure unit is designed to provide cleaning speed at 240 bar cavitation cleaning with the CW350 and ROV lances to remove marine life and instable coatings. The solid, stand-alone, 4 wheeled cart has a gasoline engine and is compatible with CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 240 bar (3,480 psi)
Max. flow: 36 LPM (9.5 GPM)
Power: 22HP Honda gasoline engine
Weight: 150kg (330 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 240 bar (3,480 psi)
Max. flow: 36 LPM (9.5 GPM)
Power: 22HP Honda gasoline engine
Weight: 150kg (330 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter
