Gasoline High Pressure Unit
High Pressure Units

Gasoline High Pressure Unit

30 LPM @ 290 bar

The gasoline engine driven HDE290_30 high pressure unit is designed to drive underwater tools or remove marine life and instable coatings with 290 bar cavitation cleaning. The solid, stand-alone, 4 wheeled cart has a gasoline engine and is compatible with the CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Gasoline High Pressure Unit

30 LPM @ 290 bar

The gasoline engine driven HDE290_30 high pressure unit is designed to drive underwater tools or remove marine life and instable coatings with 290 bar cavitation cleaning. The solid, stand-alone, 4 wheeled cart has a gasoline engine and is compatible with the CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 290 bar (4,206 psi)
Max. flow: 30 LPM (7.9 GPM)
Power: 22HP Honda gasoline engine
Weight: 150kg (330 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 290 bar (4,206 psi)
Max. flow: 30 LPM (7.9 GPM)
Power: 22HP Honda gasoline engine
Weight: 150kg (330 lbs)
Dimensions: 100x82x85cm (39.4x32.3x33.5”)

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Electric start
  • Heavy duty, 4 wheeled cart
  • Manual pressure valve
  • Readily serviceable water filter
  • Automatic decelerator to reduce RPM in the bypass phase
  • No engine-oil safety device
  • Motor thermal protection
  • Hour counter
