I-SERIES CL High Pressure Pumps

I-SERIES CL High Pressure Pumps

130 - 200 bar | 49 - 70 LPM | 17,5 - 19 kW

The CL high pressure pumps are available in 130 to 200 bar, 49 to 70 liters per minute and 17.5 to 19 kW for use in the construction, food and cleaning industry, sewer cleaning, machine building and other applications. These I-SERIES CL pumps are relatively low in pressure, but with a large displacement and available in various pump speeds from 1000 to 1450 rpm with a traditional valve mechanism for horizontal mounting. The excellent quality and reliability guarantee very high efficiency and very low operating costs.

Download the brochure for more information and technical specifications for the different models.

Download Brochure

I-SERIES CL High Pressure Pumps

130 - 200 bar | 49 - 70 LPM | 17,5 - 19 kW

The CL high pressure pumps are available in 130 to 200 bar, 49 to 70 liters per minute and 17.5 to 19 kW for use in the construction, food and cleaning industry, sewer cleaning, machine building and other applications.

Specifications

Pressure: 130 - 200 bar
Flow: 49 - 70 LPM
Power: 17,5 - 19 kW
RPM: 1000 / 1450 rpm
Montage: Horizontal
Weight: 31 / 34 kg
Pump head material: Stainless steel
Applications: Machine construction, cleaning, graffiti removal, sewer cleaning, food industry, underwater cavitation cleaning and other high pressure applications.

Features

  • Splash lubrication
  • Ceramic plungers
  • Connection kit (optional)
  • Pulse system (optional)
  • Double shaft end (optional)
  • Bell housing for hydraulic connection (optional)
  • Seal kit max. 85 degrees (optional)

Specifications

Pressure: 130 - 200 bar
Flow: 49 - 70 LPM
Power: 17,5 - 19 kW
RPM: 1000 / 1450 rpm
Montage: Horizontal
Weight: 31 / 34 kg
Pump head material: Stainless steel
Applications: Machine construction, cleaning, graffiti removal, sewer cleaning, food industry, underwater cavitation cleaning and other high pressure applications.

Features

  • Splash lubrication
  • Ceramic plungers
  • Connection kit (optional)
  • Pulse system (optional)
  • Double shaft end (optional)
  • Bell housing for hydraulic connection (optional)
  • Seal kit max. 85 degrees (optional)

Overview available CL pumps

Code Model RPM Flow Pressure Power Weight
6915 0004 CL 49/200 1000 rpm 49 l/min 200 bar 19 kW 34 kg
6915 0005 CL 66/140 1000 rpm 66 l/min 140 bar 18,5 kW 31 kg
6915 0006 CL 70/130 1450 rpm 70 l/min 130 bar 17,5 kW 34 kg
