I-SERIES GL - GLR High Pressure Pumps

I-SERIES GL - GLR High Pressure Pumps

125 - 290 bar | 109 - 256 LPM | 61,7 - 62,5 kW

The I-SERIES GL / GLR high pressure pumps are available in 125 to 290 bar, 109 to 256 liters per minute and 61.7 to 62.5 kW for use in the construction, food and cleaning industry, sewer cleaning, machine building and other applications . These I-SERIES GL / GLR pumps are relatively low in pressure with a large displacement and available in various pump speeds from 750 to 1800 rpm with a traditional valve mechanism for horizontal mounting. The excellent quality and reliability guarantee very high efficiency and very low operating costs.

Download the brochure for more information and technical specifications for the different models.

 Download Brochure

I-SERIES GL - GLR High Pressure Pumps

125 - 290 bar | 109 - 256 LPM | 61,7 - 62,5 kW

The I-SERIES GL / GLR high pressure pumps are available in 125 to 290 bar, 109 to 256 liters per minute and 61.7 to 62.5 kW for use in the construction, food and cleaning industry, sewer cleaning, machine building and other applications.

Specifications

Pressure: 125 - 290 bar
Flow: 109 - 256 LPM
Power: 61,7 - 62,5 kW
RPM: 750 - 1800 rpm
Montage: Horizontal
Weight: GL: 150 / GLR: 175 kg
Pump head material: Cast iron
Applications: Machine construction, cleaning, graffiti removal, sewer cleaning, food industry, underwater cavitation cleaning and other high pressure applications.

Features

  • Splash lubrication
  • Ceramic plungers
  • Connection kit (optional)
  • Pressure relief kit (optional)
  • Pully/ Drive shaft kit (optional)
  • Bell housing for hydraulic connection (optional)
  • Oil cooler (optional)
  • Reverse drive (optional)

Specifications

Pressure: 125 - 290 bar
Flow: 109 - 256 LPM
Power: 61,7 - 62,5 kW
RPM: 750 - 1800 rpm
Montage: Horizontal
Weight: GL: 150 / GLR: 175 kg
Pump head material: Cast iron
Applications: Machine construction, cleaning, graffiti removal, sewer cleaning, food industry, underwater cavitation cleaning and other high pressure applications.

Features

  • Splash lubrication
  • Ceramic plungers
  • Connection kit (optional)
  • Pressure relief kit (optional)
  • Pully/ Drive shaft kit (optional)
  • Bell housing for hydraulic connection (optional)
  • Oil cooler (optional)
  • Reverse drive (optional)

Overview available GL / GLR pumps

Code Model RPM Flow Pressure Power Weight
6911 0002 GL 109/290 750 rpm 109 l/min 290 bar 61,7 kW 150 kg
6911 0008 GLR 109/290 1500 rpm 109 l/min 290 bar 61,7 kW 175 kg
6911 0014 GLR 109/290 1800 rpm 109 l/min 290 bar 61,7 kW 175 kg
6911 0003 GL 135/235 750 rpm 135 l/min 235 bar 62,5 kW 150 kg
6911 0009 GLR 135/235 1500 rpm 135 l/min 235 bar 62,5 kW 175 kg
6911 0015 GLR 135/235 1800 rpm 135 l/min 235 bar 62,5 kW 175 kg
6911 0004 GL 171/185 750 rpm 171 l/min 185 bar 62,5 kW 150 kg
6911 0010 GLR 171/185 1500 rpm 171 l/min 185 bar 62,5 kW 175 kg
6911 0016 GLR 171/185 1800 rpm 171 l/min 185 bar 62,5 kW 175 kg
6911 0005 GL 212/150 750 rpm 212 l/min 150 bar 62,5 kW 150 kg
6911 0011 GLR 212/150 1500 rpm 212 l/min 150 bar 62,5 kW 175 kg
6911 0017 GLR 212/150 1800 rpm 212 l/min 150 bar 62,5 kW 175 kg
6911 0006 GL 256/125 750 rpm 256 l/min 125 bar 62,5 kW 150 kg
6911 0012 GLR 256/125 1500 rpm 256 l/min 125 bar 62,5 kW 175 kg
6911 0018 GLR 256/125 1800 rpm 256 l/min 125 bar 62,5 kW 175 kg
