P-SERIES P-150 SAP-L High Volume High Pressure Pumps

P-SERIES P-150 SAP-L High Volume High Pressure Pumps

170 - 400 bar | 151,2 - 374,6 LPM | 112 - 117,9 kW

The PTC P-150 SAP-L pumps are developed for high volumes and available in ranges from 170 to 400 bar, 151.2 to 1156.2 LPM and 112 to 117.9 kW for sewer cleaning, road renovation, concrete bridges and viaducts , pillars, scaffolding and walls, tank cleaning and other high flow applications. The P-150 SAP-L high pressure pumps are equipped with a conventional valve mechanism for horizontal mounting (1500 / 1800RPM).

Download the brochure for more information and technical specifications for the different models.

 Download Brochure

P-SERIES P-150 SAP-L High Volume High Pressure Pumps

170 - 400 bar | 151,2 - 374,6 LPM | 112 - 117,9 kW

The PTC P-150 SAP-L pumps are developed for high volumes and available in ranges from 170 to 400 bar, 151.2 to 1156.2 LPM and 112 to 117.9 kW for sewer cleaning, road renovation, concrete bridges and viaducts , pillars, scaffolding and walls, tank cleaning and other high flow applications.

Specifications

Pressure: 170 - 400 bar
Flow: 151,2 - 374,6 LPM
Power: 112 - 117,9 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 170 - 400 bar
Flow: 151,2 - 374,6 LPM
Power: 112 - 117,9 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-150 SAP-L pumps

V-Model/Code H-Model/Code RPM Flow Pressure Power Weight
P231554V31400 P231554H31400 1500 rpm 155,9 l/min 400 bar 115,5 kW 400 kg
P231564V31400 P231564H31400 1800 rpm 151,2 l/min 400 bar 112 kW 400 kg
P231554V31450 P231554H31450 1500 rpm 197,3 l/min 320 bar 116,9 kW 400 kg
P231564V31450 P231564H31450 1800 rpm 191,4 l/min 320 bar 113,4 kW 400 kg
P231554V31500 P231554H31500 1500 rpm 243,6 l/min 260 bar 117,3 kW 400 kg
P231564V31500 P231564H31500 1800 rpm 236,3 l/min 260 bar 113,8 kW 400 kg
P231554V31550 P231554H31550 1500 rpm 294,8 l/min 215 bar 117,4 kW 400 kg
P231564V31550 P231564H31550 1800 rpm 285,9 l/min 215 bar 113,8 kW 400 kg
P231554V31620 P231554H31620 1500 rpm 374,6 l/min 170 bar 117,9 kW 400 kg
P231564V31620 P231564H31620 1800 rpm 363,3 l/min 170 bar 114,4 kW 400 kg
