P-SERIES P-200 SAP-L High Volume High Pressure Pumps

P-SERIES P-200 SAP-L High Volume High Pressure Pumps

190 - 450 bar | 179 - 433 LPM | 148,9 - 152,3 kW

The PTC P-200 SAP-L pumps are designed for high volumes and available in ranges from 190 to 450 bar, 179 to 433 LPM and 148.9 to 152.3 kW for sewer cleaning, road renovation, concrete bridges and viaducts, pillars , scaffolding and walls, tank cleaning and other high flow applications. The P-200 SAP-L high pressure pumps are equipped with a conventional valve mechanism for horizontal mounting (1500 / 1800RPM).

Download the brochure for more information and technical specifications for the different models.

 Download Brochure

P-SERIES P-200 SAP-L High Volume High Pressure Pumps

190 - 450 bar | 179 - 433 LPM | 148,9 - 152,3 kW

The PTC P-200 SAP-L pumps are designed for high volumes and available in ranges from 190 to 450 bar, 179 to 433 LPM and 148.9 to 152.3 kW for sewer cleaning, road renovation, concrete bridges and viaducts, pillars , scaffolding and walls, tank cleaning and other high flow applications.

Specifications

Pressure: 190 - 450 bar
Flow: 179 - 433 LPM
Power: 148,9 - 152,3 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 190 - 450 bar
Flow: 179 - 433 LPM
Power: 148,9 - 152,3 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-200 SAP-L pumps

V-Model/Code H-Model/Code RPM Flow Pressure Power Weight
P232054V31400 P232054H31400 1500 rpm 180,2 l/min 450 bar 150,2 kW 500 kg
P232064V31400 P232064H31400 1800 rpm 179 l/min 450 bar 149,2 kW 500 kg
P232054V31450 P232054H31450 1500 rpm 228,1 l/min 355 bar 150 kW 500 kg
P232064V31450 P232064H31450 1800 rpm 226,5 l/min 355 bar 148,9 kW 500 kg
P232054V31500 P232054H31500 1500 rpm 281,6 l/min 290 bar 151,2 kW 500 kg
P232064V31500 P232064H31500 1800 rpm 279,7 l/min 290 bar 150,2 kW 500 kg
P232054V31550 P232054H31550 1500 rpm 340,7 l/min 240 bar 151,4 kW 500 kg
P232064V31550 P232064H31550 1800 rpm 338,4 l/min 240 bar 150,4 kW 500 kg
P232054V31620 P232054H31620 1500 rpm 433 l/min 190 bar 152,3 kW 500 kg
P232064V31620 P232064H31620 1800 rpm 430 l/min 190 bar 151,3 kW 500 kg
