P-SERIES P-300 SAP-L High Volume High Pressure Pumps

P-SERIES P-300 SAP-L High Volume High Pressure Pumps

320 - 750 bar | 177,2 - 435,6 LPM | 246,2 - 258,1 kW

The PTC P-300 SAP-L pumps are developed for high volumes and available in ranges from 320 to 750 bar, 177.2 to 435.6 LPM and 246.2 to 258.1 kW for sewer cleaning, road renovation, concrete bridges and viaducts, pillars, scaffolding and walls, tank cleaning and other high flow applications. The P-300 SAP-L high pressure pumps are equipped with a conventional valve mechanism for horizontal mounting (1500 / 1800RPM).

Download the brochure for more information and technical specifications for the different models.

 Download Brochure

P-SERIES P-300 SAP-L High Volume High Pressure Pumps

320 - 750 bar | 177,2 - 435,6 LPM | 246,2 - 258,1 kW

The PTC P-300 SAP-L pumps are developed for high volumes and available in ranges from 320 to 750 bar, 177.2 to 435.6 LPM and 246.2 to 258.1 kW for sewer cleaning, road renovation, concrete bridges and viaducts, pillars, scaffolding and walls, tank cleaning and other high flow applications.

Specifications

Pressure: 320 - 750 bar
Flow: 177,2 - 435,6 LPM
Power: 246,2 - 258,1 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 320 - 750 bar
Flow: 177,2 - 435,6 LPM
Power: 246,2 - 258,1 kW
RPM: 1500/1800 RPM
Montage: Horizontal
Applications: Sewer cleaning, renovation of roads, concrete bridges and viaducts, pillars, jetties and walls, tank cleaning and other high flow applications

Features

  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-300 SAP-L pumps

V-Model/Code H-Model/Code RPM Flow Pressure Power Weight
P233154V31400 P233154H31400 1500 rpm 177,2 l/min 750 bar 246,2 kW 700 kg
P233164V31400 P233164H31400 1800 rpm 181,3 l/min 750 bar 251,8 kW 700 kg
P233154V31450 P233154H31450 1500 rpm 224,3 l/min 600 bar 249,3 kW 700 kg
P233164V31450 P233164H31450 1800 rpm 229,5 l/min 600 bar 255 kW 700 kg
P233154V31500 P233154H31500 1500 rpm 276,9 l/min 490 bar 251,3 kW 700 kg
P233164V31500 P233164H31500 1800 rpm 183,3 l/min 490 bar 257,1 kW 700 kg
P233154V31550 P233154H31550 1500 rpm 335,1 l/min 400 bar 248,2 kW 700 kg
P233164V31550 P233164H31550 1800 rpm 342,8 l/min 400 bar 253,9 kW 700 kg
P233154V31620 P233154H31620 1500 rpm 425,8 l/min 320 bar 252,3 kW 700 kg
P233164V31620 P233164H31620 1800 rpm 435,6 l/min 320 bar 258,1 kW 700 kg
