P-SERIES P-100 SAP High Pressure Pumps

P-SERIES P-100 SAP High Pressure Pumps

270 - 1400 bar | 30,6 - 155,9 LPM | 70 - 84,9 kW

The P-100 SERIES SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 270 to 1400 bar, 30.6 to 155.9 LPM and 70 to 84.9 kW for concrete renovation and hydrodemolition, tank - and ship cleaning and other applications with hot and cold water. The P-100 SERIES SAP high pressure pumps are made of high quality materials.

  • Pump head with INTELLIVALVE cartridge technology
  • Increased component life

Download the brochure for more information and technical specifications for the different models.

 Download Brochure

P-SERIES P-100 SAP High Pressure Pumps

270 - 1400 bar | 30,6 - 155,9 LPM | 70 - 84,9 kW

The PTC P-100 SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 270 to 1400 bar, 30.6 to 155.9 LPM and 70 to 84.9 kW for concrete renovation and hydrodemolition, tank- and ship cleaning and other applications with hot and cold water.

P-SERIES P-100 SAP 270-1400 bar High Pressure Pumps

Specifications

Pressure: 270 - 1400 bar
Flow: 30,6 - 155,9 LPM
Power: 70 - 84,9 kW
RPM: 1500/ 1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Applications: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 270 - 1400 bar
Flow: 30,6 - 155,9 LPM
Power: 70 - 84,9 kW
RPM: 1500/ 1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Applications: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-100 SAP pumps

H-Model/Code RPM Flow Pressure Power Weight
P231152H34180 1500 rpm 31,6 l/min 1400 bar 81,9 kW 400 kg
P231162H34180 1800 rpm 30,6 l/min 1400 bar 79,4 kW 400 kg
P231152H34200 1500 rpm 39 l/min 1000 bar 72,2 kW 400 kg
P231162H34200 1800 rpm 37,8 l/min 1000 bar 70 kW 400 kg
P231152H34220 1500 rpm 47,2 l/min 900 bar 78,6 kW 400 kg
P231162H34220 1800 rpm 47,2 l/min 900 bar 76,2 kW 400 kg
P231152H34240 1500 rpm 56,1 l/min 750 bar 78 kW 400 kg
P231162H34240 1800 rpm 54,4 l/min 750 bar 75,6 kW 400 kg
P231152H34260 1500 rpm 65,9 l/min 650 bar 79,3 kW 400 kg
P231162H34260 1800 rpm 63,9 l/min 650 bar 76,9 kW 400 kg
P231152H34280 1500 rpm 76,4 l/min 600 bar 84,9 kW 400 kg
P231162H34280 1800 rpm 74,1 l/min 600 bar 82,3 kW 400 kg
P231152H34300 1500 rpm 87,7 l/min 500 bar 81,2 kW 400 kg
P231162H34300 1800 rpm 85,1 l/min 500 bar 78,8 kW 400 kg
P231152H34320 1500 rpm 99,8 l/min 420 bar 77,6 kW 400 kg
P231162H34320 1800 rpm 96,8 l/min 420 bar 75,3 kW 400 kg
P231152H34350 1500 rpm 119,4 l/min 330 bar 73 kW 400 kg
P231152H34350 1800 rpm 115,8 l/min 330 bar 70,7 kW 400 kg
P231152H34400 1500 rpm 155,9 l/min 270 bar 78 kW 400 kg
P231162H34400 1800 rpm 151,2 l/min 270 bar 75,6 kW 400 kg
