P-SERIES P-200 SAP High Pressure Pumps

P-SERIES P-200 SAP High Pressure Pumps

450-1470 bar | 54,1 - 180,2 LPM | 147,4 - 169,2 kW

The PTC P-200 SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 450 to 1470 bar, 54.1 to 180.2 LPM and 147.4 to 169.2 kW for concrete renovation and hydrodemolition, tank and ship cleaning and other applications with hot and cold water. The P-200 SAP high pressure pumps can be mounted both horizontally and vertically (1500/1800 RPM).

  • Pump head with INTELLIVALVE cartridge technology
  • Increased component life
  • For horizontal and vertical applications

 Download the brochure for more information and technical specifications for the different models.

 Download Brochure

P-SERIES P-200 SAP High Pressure Pumps

450-1470 bar | 54,1 - 180,2 LPM | 147,4 - 169,2 kW

The PTC P-200 SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 450 to 1470 bar, 54.1 to 180.2 LPM and 147.4 to 169.2 kW for concrete renovation and hydrodemolition, tank and ship cleaning and other applications with hot and cold water.

Specifications

Pressure: 450 - 1470 bar
Flow: 54,1 - 180,2 LPM
Power: 147,4 - 169,2 kW
RPM: 1500/ 1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Application: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steal pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 450 - 1470 bar
Flow: 54,1 - 180,2 LPM
Power: 147,4 - 169,2 kW
RPM: 1500/ 1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Application: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steal pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-200 SAP pumps

V-Model/Code H-Model/Code RPM Flow Pressure Power Weight
P232052V34220 P232052H34220 1500 rpm 54,5 l/min 1470 bar 148,4 kW 500 kg
P232062V34220 P232062H34220 1800 rpm 54,1 l/min 1470 bar 147,4 kW 500 kg
P232052V34240 P232052H34240 1500 rpm 64,9 l/min 1300 bar 156,2 kW 500 kg
P232062V34240 P232062H34240 1800 rpm 64,4 l/min 1300 bar 155,1 kW 500 kg
P232052V34260 P232052H34260 1500 rpm 76,1 l/min 1200 bar 169,2 kW 500 kg
P232062V34260 P232062H34260 1800 rpm 75,6 l/min 1200 bar 168 kW 500 kg
P232052V34280 P232052H34280 1500 rpm 88,3 l/min 1000 bar 163,5 kW 500 kg
P232062V34280 P232062H34280 1800 rpm 87,7 l/min 1000 bar 162,4 kW 500 kg
P232052V34300 P232052H34300 1500 rpm 101,4 l/min 800 bar 150,2 kW 500 kg
P232062V34300 P232062H34300 1800 rpm 100,7 l/min 800 bar 149,2 kW 500 kg
P232052V34320 P232052H34320 1500 rpm 115,3 l/min 700 bar 149,5 kW 500 kg
P232062V34320 P232062H34320 1800 rpm 114,5 l/min 700 bar 148,5 kW 500 kg
P232052V34350 P232052H34350 1500 rpm 138 l/min 600 bar 153,3 kW 500 kg
P232062V34350 P232062H34350 1800 rpm 137 l/min 600 bar 152,3 kW 500 kg
P232052V34400 P232052H34400 1500 rpm 180,2 l/min 450 bar 150,2 kW 500 kg
P232062V34400 P232062H34400 1800 rpm 179 l/min 450 bar 149,2 kW 500 kg
