P-SERIES P-300 SAP High Pressure Pumps

P-SERIES P-300 SAP High Pressure Pumps

750 - 1400 bar | 99,7 - 181,3 LPM | 246,2 - 264,4 kW

The PTC P-300 SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 750 to 1400 bar, 99.7 to 181.3 LPM and 246.2 to 264.4 kW for concrete renovation and hydrodemolition, tank and ship cleaning and other applications with hot and cold water. The P-300 SAP high pressure pumps can be mounted both horizontally and vertically (1500/1800 RPM).

  • Pump head with INTELLIVALVE cartridge technology
  • Increased component life
  • For horizontal and vertical applications

Download the brochure for more information and technical specifications for the different models.

Download Brochure

P-SERIES P-300 SAP High Pressure Pumps

750 - 1400 bar | 99,7 - 181,3 LPM | 246,2 - 264,4 kW

The PTC P-300 SAP Heavy Duty pumps are equipped with the INTELLIVALVE “cartridge” valve mechanism and are available in ranges from 750 to 1400 bar, 99.7 to 181.3 LPM and 246.2 to 264.4 kW for concrete renovation and hydrodemolition, tank and ship cleaning and other applications with hot and cold water.

Specifications

Pressure: 750 - 1400 bar
Flow: 99,7 - 181,3 LPM
Power: 246,2 - 264,4 kW
RPM: 1500/1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Applications: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Specifications

Pressure: 750 - 1400 bar
Flow: 99,7 - 181,3 LPM
Power: 246,2 - 264,4 kW
RPM: 1500/1800 RPM
Use: Warm and cold water
Montage: Horizontal and vertical
Applications: Concrete renovation, hydrodemolition, tank and ship cleaning, etc.

Features

  • Intellivalve cartridge technology
  • Stainless steel pump head
  • Tungsten carbide plunger
  • Forced lubrication
  • Long lifespan

Overview available P-150 SAP pumps

V-Model/Code H-Model/Code RPM Flow Pressure Power Weight
P233152V34300 P233152H34300 1500 rpm 99,7 l/min 1400 bar 258,5 kW 700 kg
P233162V34300 P233162H34300 1800 rpm 102 l/min 1400 bar 264,4 kW 700 kg
P233152V34320 P233152H34320 1500 rpm 113,4 l/min 1200 bar 252,1 kW 700 kg
P233162V34320 P233162H34320 1800 rpm 116 l/min 1200 bar 257,9 kW 700 kg
P233152V34350 P233152H34350 1500 rpm 135,7 l/min 1000 bar 251,3 kW 700 kg
P233162V34350 P233162H34350 1800 rpm 138,8 l/min 1000 bar 257,1 kW 700 kg
P233152V34400 P233152H34400 1500 rpm 177,2 l/min 750 bar 246,2 kW 700 kg
P233162V34400 P233162H34400 1800 rpm 181,3 l/min 750 bar 251,8 kW 700 kg
