HDMD-P150 Diesel High Pressure Unit

HDMD-P150 Diesel High Pressure Unit

2800 bar | 156 LPM | 122 kW

The HDMD-P150 high-pressure unit offers an unbeatable price/quality ratio. Powered by powerful Volvo stage-V diesel engine and ideal for industrial cleaning and hydrodemolotion.
Quick start-up and easy-to-use with convenient connections and modern electronic controls that allow smooth integration with (semi) automatic and robot applications.
The patented intellivalve pump head saves time and costs during maintenance or fluid ends conversions.

PRO-JETTING has certified technicians, a wide range of high-pressure components and spare parts, and its own engineering. Available with a maximum pressure up to 2800 bar (40000 psi), a flow up to 156 LPM (6 - 40 GPM) and a power up to 122 kW as skid, trailer or compact soundproof canopy.

View the complete production line at the bottom of the page or contact us and we will look together for the best solution for your application.

Download Brochure

HDMD-P150 Diesel High Pressure Unit

2800 bar | 156 LPM | 122 kW

The P150 diesel high pressure unit is available as a trailer, skid or powerpack up to 2800 bar and 122 KW (160 HP). Top quality at an affordable price for industrial cleaning and hydrodemolotion.

Specifications

Pressure: 560 - 2800 bar (8,100 - 40,000 psi)
Flow: 23 - 156 LPM (6 - 40 GPM)
Power: 116 - 122 kW
Drive: Diesel
Available at: Soundproof Canopy, Skid of Trailer
Applications: Industrial maintaince, Concrete renovation and industrial applications

Features

  • Very good price/quality ratio
  • Quick delivery
  • Easy to maintain
  • Easy to convert
  • Compact
  • Stage V Volvo diesel engine
  • Low noise
  • Electronic control for automation
  • Suitable for automatic and robot applications
  • Stainless Steel Pump
  • Intellivalve pump
  • User-friendly connections
  • Emergency stop
  • SIR certified
  • Optional: Customization

Specifications

Pressure: 560 - 2800 bar (8,100 - 40,000 psi)
Flow: 23 - 156 LPM (6 - 40 GPM)
Power: 116 - 122 kW
Drive: Diesel
Available at: Soundproof Canopy, Skid of Trailer
Applications: Industrial maintaince, Concrete renovation and industrial applications

Features

  • Very good price/quality ratio
  • Quick delivery
  • Easy to maintain
  • Easy to convert
  • Compact
  • Stage V Volvo diesel engine
  • Low noise
  • Electronic control for automation
  • Suitable for automatic and robot applications
  • Stainless Steel Pump
  • Intellivalve pump
  • User-friendly connections
  • Emergency stop
  • SIR certified
  • Optional: Customization

Available options for the HDMD-P150

Code Plunjer ⌀ Flow Druk Vermogen
HDMD-2800_23 16 mm 22,5 LPM (5,9 GPM) 2800 bar (40.600 psi) 116,4 kW (158 HP)
HDMD-2200_28 18 mm 28,4 LPM (7,5 GPM) 2200 bar (31.900 psi) 115,8 kW ( 157 HP)
HDMD-1800_35 20 mm 35,1 LPM (9,3 GPM) 1800 bar ( 26.100 psi) 116,9 kW ( 159 HP)
HDMD-1400_47 22 mm 47,2 LPM (12,5 GPM) 1400 bar (20.300 psi) 122,3 kW (166 HP)
HDMD-1200_56 24 mm 56,1 LPM (14,8 GPM) 1200 bar (17.400 psi) 124,7 kW (170 HP)
HDMD-1000_66 26 mm 65,9 LPM (17,4 GPM) 1000 bar (14.500 psi) 122 kW (166 HP)
HDMD-830_76 28 mm 76,4 LPM (20,2 GPM) 830 bar (12.035 psi) 117,4 kW (160 HP)
HDMD-750_88 30 mm 87,7 LPM (23,2 GPM) 750 bar (10.875 psi) 121,8 kW (166 HP)
HDMD-640_100 32 mm 99,8 LPM (26,4 GPM) 640 bar (9280 psi) 118,3 kW (156 HP)
HDMD-560_119 35 mm 119,4 LPM (31,5 GPM) 560 bar (8120 psi) 123,8 kW (168 HP)
HDMD-400_156 40 mm 155,9 LPM (41,2 GPM) 400 bar (5800 psi) 115,5 kW (157 HP)
