NX608 Ultraflex Hose
NX608 Ultraflex

NX608 Ultraflex Hose

1/2" (DN12) - 1 1/4" (DN32)

The NX608 is one of the most flexible sewer hoses. This plastic sewer hose is resistant to kinking. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber sewer hoses. The weight of the hose also plays a major role in this.

Contact PRO-JETTING now and ask about the affordable offer.

 Download Brochure

NX608 Ultraflex Hose

1/2" (DN12) - 1 1/4" (DN32)

The NX608 is one of the most flexible sewer hoses. This plastic sewer hose is resistant to kinking. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber sewer hoses. The weight of the hose also plays a major role in this.

Specifications

Core: Polyether polyurethane
Strengthening: Aramid fiber
Surface: Polyurethane
Temperature: 40°C to +60°C

Features

  • Very Flexible
  • Smooth surface
  • Low flow resistance

Specifications

Core: Polyether polyurethane
Strengthening: Aramid fiber
Surface: Polyurethane
Temperature: 40°C to +60°C

Features

  • Very Flexible
  • Smooth surface
  • Low flow resistance

NX608 Ultraflex

code DN I.D. O.D. W.P. B.P. buig radius
NX608-8 12 1/2" 21mm 275 bar (4,000 psi) 1100bar (16,000 psi) 80mm
NX608-12 20 3/4" 29mm 250 bar (3,600 psi) 625 bar (9,050 psi) 125mm
NX608-16 25 1" 37mm 250 bar (3,600 psi) 625 bar (9,050 psi) 150mm
NX608-20 32 1 1/4" 46mm 250 bar (3,600 psi) 625 bar (9,050 psi) 250mm
