NX649 Ultraflex Hose
NX649 Ultraflex

NX649 Ultraflex Hose

3/16"(DN5) - 3/8" (DN10)

The NX649 is one of the most flexible sewer hoses. This plastic sewer hose is resistant to kinking. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber sewer hoses. The NX649 is mainly used for smaller drain pipes with many bends.

Contact PRO-JETTING now and ask about the affordable offer.

NX649 Ultraflex Hose

3/16"(DN5) - 3/8" (DN10)

The NX649 is one of the most flexible sewer hoses. This plastic sewer hose is resistant to kinking. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber sewer hoses. The NX649 is mainly used for smaller drain pipes with many bends.

Specifications

Core: Polyether polyurethame
Strengthening: Aramid fiber
Surface: Polyurethane
Temperature: 40°C to +70°C

Features

  • Very flexible
  • Smooth surface
  • Low flow resistance

Specifications

Core: Polyether polyurethame
Strengthening: Aramid fiber
Surface: Polyurethane
Temperature: 40°C to +70°C

Features

  • Very flexible
  • Smooth surface
  • Low flow resistance

NX649 Ultraflex

code DN I.D. O.D. W.P. B.P. buig radius
NX649-3 5 3/16" 10mm 560bar 1400bar 25mm
NX649-4 6 1/4" 12.5mm 560bar 1400bar 32mm
NX649-5 8 5/16" 14mm 480bar 1200bar 45mm
NX649-6 10 3/8" 16mm 440bar 1120bar 55mm
