VAN Pack

VAN Pack

160 - 200 bar | 55 - 60 LPM

Simplicity and mobility. This unit is built on a skid so that it can easily be moved with the help of a forklift truck. Thanks to the water tank, the forklift Skid can be used in all places.

These VAN Packs are available with a pressure of 160 - 200 bar, a water output of 55 - 60 LPM and a capacity of 14.7 - 17.7 kW. These VAN Packs are relatively low in pressure, but because of their high water yield and compact construction, they are very suitable for working in locations that are difficult to access.

For more information contact us now.

Download Brochure

VAN Pack

160 - 200 bar | 55 - 60 LPM

The VAN packs are available with a capacity of 14.7 - 17.7 kW. These VAN Packs are relatively low in pressure, but because of their high water yield and compact construction, they are very suitable for working in locations that are difficult to access.

Specifications

Drive: (Pulse) Petrol
HP reel: 60m 1/2" High pressure hose
LP reel: 35m 3/4" low pressure hose
Tank capacity: 300 / 500 / 800 or 1000 L

Features

  • Easy to install and service
  • Customization possible
  • Manual pressure regulator
  • SIR certified
  • Pulse system (optional)
  • Electric reel (optional)
  • Remote control (optional)
  • Control panel (optional)

Specifications

Drive: (Pulse) Petrol
HP reel: 60m 1/2" High pressure hose
LP reel: 35m 3/4" low pressure hose
Tank capacity: 300 / 500 / 800 or 1000 L

Features

  • Easy to install and service
  • Customization possible
  • Manual pressure regulator
  • SIR certified
  • Pulse system (optional)
  • Electric reel (optional)
  • Remote control (optional)
  • Control panel (optional)

Available options for the Van Pack

Model Flow Pressure Power Engine Weight (without tank) Dimensions
VPMP160-55 55 LPM (14,5GPM) 160 bar (2320psi) 17,7 kW (24HP) Honda Petrol GX690 300 kg (660lbs) L1260 x W1000 x H1100
VPMPP160-55 55 LPM (14,5GPM) 160 bar (2320psi) 17,7 kW (22HP) Honda Petrol 250 kg (550lbs) L1260 x W1000 x H1100
VPMP200-60 60 LPM (15,6GPM) 200 bar (2900psi) 25,7 kW (35HP) Vanguard Petrol 350 kg (770lbs) L710 x W1100 x H1200
