Zero Thrust Cavitation Cleaning Gun

Zero Thrust Cavitation Cleaning Gun

CW1500 - max. 1500 bar (21,755psi)

The CW1500 zero thrust cavitation cleaning gun is used according IMCA guidelines for extremely fast removal of corrosion, dirt, debris, fouling, corrosion, instable coatings and other deposits from ship hulls, propellers, thrusters, rudders, pillars, pipelines, piers, risers and walls. The CW1500 is safe and ergonomic to use with a long zero thrust lance to neutralize the reaction force of the cavitation blast and avoid diver fatigue.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Zero Thrust Cavitation Cleaning Gun

CW1500 - max. 1500 bar (21,755psi)

The CW1500 is used according IMCA guidelines for extremely fast removal of corrosion, dirt, debris, fouling, instable coatings and other deposits from ship hulls, propellers, pillars, pipelines, piers, walls and other structures.

Specifications

Minimum pressure: 300 bar (4,350 psi)
Maximum pressure: 1500 bar (21,755 psi)
Minimum flow: 80LPM (21 GPM)
Maximum flow: 120 LPM (31 GPM)
Lance length: 750mm (29.5”)
Zero thrust lance length: 1000 mm (39.4”)
Weight: 2500g (5.5lbs)
Weight under water: 1400g (3.1lbs)
According: IMCA guidelines
Certified: SIR
Compatible with: HDMDSAP300_PP

Features

  • Improved cavitation technique
  • Zero thrust lance to neutralize reaction force
  • Intensity adjustable with high-pressure unit
  • Durable, salt water resistant materials
  • Double-walled stainless steel lance
  • Tapered lance tip with visible cover ring
  • Ergonomic controls
  • Large control lever with “Safety catch”
  • Swiveling connection
  • Use with single neutrally buoyant high-pressure hose

Specifications

Minimum pressure: 300 bar (4,350 psi)
Maximum pressure: 1500 bar (21,755 psi)
Minimum flow: 80LPM (21 GPM)
Maximum flow: 120 LPM (31 GPM)
Lance length: 750mm (29.5”)
Zero thrust lance length: 1000 mm (39.4”)
Weight: 2500g (5.5lbs)
Weight under water: 1400g (3.1lbs)
According: IMCA guidelines
Certified: SIR
Compatible with: HDMDSAP300_PP

Features

  • Improved cavitation technique
  • Zero thrust lance to neutralize reaction force
  • Intensity adjustable with high-pressure unit
  • Durable, salt water resistant materials
  • Double-walled stainless steel lance
  • Tapered lance tip with visible cover ring
  • Ergonomic controls
  • Large control lever with “Safety catch”
  • Swiveling connection
  • Use with single neutrally buoyant high-pressure hose
