Electric High Pressure Unit

Electric High Pressure Unit

42 LPM @ 210 bar

The electric HDE210_42 high pressure unit is a very cost efficient, semi professional, high pressure unit with a 42 LPM flow, which means cleaning underwater surfaces fast with retro guns, surface rotors or ROV lances. The solid 4 wheeled cart requires a 18,5Kw three-phase power supply and is compatible with the CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

Download Brochure

Electric High Pressure Unit

42 LPM @ 210 bar

The electric HDE210_42 high pressure unit is a very cost efficient, semi professional, high pressure unit with a 42 LPM flow, which means cleaning underwater surfaces fast with retro guns, surface rotors or ROV lances. The solid 4 wheeled cart requires a 18,5Kw three-phase power supply and is compatible with the CW300, CW350, SR450, SR600, all ROV lances and all underwater tools.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 210 bar (3,045 psi)
Max. flow: 42 LPM (11 GPM)
Power: 14,7Kw, 400v, 50Hz
Weight: 185kg (187lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Optional with frequency controller for continuous adjustment of pressure and flow.

Specifications

Compatible with: CW300, CW350, CW202ROV, CW303ROV, SR450, SR600, All Underwater Tools
Max. Pressure: 210 bar (3,045 psi)
Max. flow: 42 LPM (11 GPM)
Power: 14,7Kw, 400v, 50Hz
Weight: 185kg (187lbs)
Dimensions: 100x75x85cm (39.4x29.5x33.5")

Features

  • Removes medium fouling, debris, corrosion and instable coatings
  • Drives all underwater tools
  • Heavy duty, 4 wheeled cart
  • Stainless steel cover
  • Big cartridge filter at pump inlet
  • Manual pressure valve
  • Motor thermal protection
  • Hour counter
  • Emergency stop
  • Optional with frequency controller for continuous adjustment of pressure and flow.
