VAN Pack XL PRO
PRO-JETTING/1170x312/pro-jetting-van-pack-1170x-312.mp4

VAN Pack XL PRO

150 - 200 bar | 48 - 84 LPM

The compact PRO XXL Van Pack is built with a Stage V Diesel engine and powerful PRO-JETTING  48 - 84 LPM, 150 - 200 bar high pressure pump for cleaning pipelines up to 600mm. The clean and reliable Stage V Yanmar engine and stainless steel frame assure long lifetimes of this Van Pack.

The powerful hydraulic reel is mounted on a swinging frame that allows 90 + 180 degrees of movement for easy positioning and effortless cleaning as far as 120 meters. The second reel is easy accessible for filling the water tank with 50 m of ¾” filling hose.

Would you like to know more or are you curious about a demo? Then contact us now, we are happy to help you.

 Download Brochure

VAN Pack XL PRO

150 - 200 bar | 48 - 84 LPM

Compact, easy to operate and powerful. This Van Pack Unit is fully equipped and designed for user comfort. Optionally expandable as required.

PRO-JETTING VAN Pack XL PRO
PRO-JETTING VAN Pack XL PRO
PRO-JETTING VAN Pack XL PRO
PRO-JETTING VAN Pack XL PRO

Specifications

Drive: Diesel
Dimensions : L1200xW1200xH1100 mm
Motor: Yanmar Stage V Diesel 4TNV98 - 67.5 HP - 35L Diesel tank
High Pressure Hose reel (primary reel): Max. 80m ½” - 90◦ Rotating - 180◦ Swiveling - Freewheel function
Low pressure hose reel (secondary reel): Max. 35m ¾” filling hose
Water tank : 300 | 500 | 800 |1000 L

Features

  • Compact and lightweight
  • Stainlesssteel frame
  • Electric High Pressure Reel
  • Protection : Overpressure protection - Filter/pre-pressure protection - Dry-run protection - Engine temperature protection - Engine oil protection - Hydraulics temperature protection
  • Remote control: Engine START/STOP - Primary reel IN/OUT - Pump ON/OFF - Pressure (RPM) UP/DOWN - Emergency STOP
  • SIR & CE certified
  • Optional: Distance measurement - Ventury-injector system for filling tank - C70 Video nozzle
  • Customization possible

Specifications

Drive: Diesel
Dimensions : L1200xW1200xH1100 mm
Motor: Yanmar Stage V Diesel 4TNV98 - 67.5 HP - 35L Diesel tank
High Pressure Hose reel (primary reel): Max. 80m ½” - 90◦ Rotating - 180◦ Swiveling - Freewheel function
Low pressure hose reel (secondary reel): Max. 35m ¾” filling hose
Water tank : 300 | 500 | 800 |1000 L

Features

  • Compact and lightweight
  • Stainlesssteel frame
  • Electric High Pressure Reel
  • Protection : Overpressure protection - Filter/pre-pressure protection - Dry-run protection - Engine temperature protection - Engine oil protection - Hydraulics temperature protection
  • Remote control: Engine START/STOP - Primary reel IN/OUT - Pump ON/OFF - Pressure (RPM) UP/DOWN - Emergency STOP
  • SIR & CE certified
  • Optional: Distance measurement - Ventury-injector system for filling tank - C70 Video nozzle
  • Customization possible

Available options for the VAN Pack XL PRO

Model Flow Pressure Power Enigne
VPMD200-60 60 LPM (15,6GPM) 200 bar (2900psi) 26,5 kW (36HP) Yanmar 3TNV88 Stage V
VPMD190-84 84 LPM (22,2GPM) 190 bar (2755psi) 35,3 kW (48HP) Yanmar 4TNV88 Stage V
VPMD150-102 102 LPM (27GPM) 150 bar (2175psi) 35,3 kW (48HP) Yanmar 4TNV88 Stage V
VPMPTO190-84 84 LPM (22,2GPM) 190 bar (2755psi) 35,3 kW (48HP) Hydraulic PTO vehicle
VPMPTO150-102 102 LPM (27GPM) 150 bar (2175psi) 35,3 kW (48HP) Hydraulic PTO vehicle
